Applicable compressor power: 10HP
Power Supply: 380VAC; 50/60HZ
Two-way signal input: temperature probe sensor, defrost probe sensor
Three-way control output: compressor, defrosting, fan
Temperature Measurement Range: -50~50℃
Temperature Control Range: -40~119℃
Temperature Measurement Accuracy: ±1℃
Resolution: 0.1℃
Compressor Delay Protection Time: 1~120 min adjustable
The maximum continuous output current of compressor loop: 21A (10HP)
The maximum continuous output current of defrosting loop: 21A (10HP)
The maximum continuous output current of fan loop: 7A (10HP)
Sensor type: NTC (10KΩ/25℃, B value 3435K)
Communication: RS-485
