Applicable compressor power: 15HP
Power supply: Three-phase five-wire (or three -phase
four-wire) 380 V A C±10 % / 50 Hz
Measurement temperature range: -49℃~119 ℃/
-56~212 ℉
Temperature measurement accuracy: - 20℃~
50 ℃±
1℃/
±2℉, others±
1.5℃/±
3℉
Temperature control range: -49℃~119 ℃/
-56~212 ℉
Temperature resolution: 0.1℃/1 ℃ or1F
Current measurement range: 0-40A
Current display resolution: 0.1A
Current detection accuracy: 0- 30A±2A, others ±5%
Relay contact output capacity: 5A/240VAC
Maximum allowable continuous output current of compressor circuit: 30A (15HP)
Maximum allowable continuous output current of defrosting circuit: 30A (15HP)
Maximum allowable continuous output current of fan circuit: 7A
Working environment: -10℃~50℃/14~122 ℉
Sensor type: NTC (10K Ω/25 ℃, B value 3435K)
Sensor Cable Length: 2m/ 5m (including probe length) 3
sensors
Box size: Width 275mm* Height 420mm* Depth 125mm
