Applicable compressor power: 5HP
Supply voltage: 3-phase 5-wire or 3-phase 4-wire 380VAC±10% 50/60HZ
Temperature range: -40℃~100℃
Temperature accuracy: ±1℃
Temperature control range: -40℃~85℃
Temperature resolution: 0.1℃
Current measuring range: 0~80A
Current measuring accuracy: ±3% (within nominal range of the mutual inductor) and ±2A (0~30A)
Current display resolution: 0.1A
Condenser type: Air cooled
Defrost mode: Electric
Temperature sensor type: NTC (10KΩ/25℃, B value 3435K) (sensor length 5m)
Compressor protection output delay: 1~120 min, adjustable
The maximum continuous output current of compressor loop: 10A (5HP)
The maximum continuous output current of defrosting loop: 10A (5HP)
The maximum continuous output current of fan loop: 5A
The maximum continuous output current of cold storage light loop: 5A/220VAC (inductive load)
Dimensions (W*H*D): 380*329*140mm
Color: white
Service environment: temperature: -10℃~60℃; humidity: 20%~90%RH
