Temperature Range:
@ 20ºC: -38C to 160 C
@ 0ºC: -50 to 160°C
Stability:
As Liquid Bath: ± 0.01 °C
As Dry block: ± 0.01 °C
Uniformity as Liquid Bath:
Axial: ± 0.02 °C @ -10 °C
: ± 0.02 °C@ 0°C
: ± 0.01 °C @ 120 °C
Radial: ± 0.01 °C @ -10 °C
: ± 0.01 °C@ 0°C
: ± 0.02 °C @ 120 °C
Accuracy:
with Internal Sensor: ± 0.15 °C
with External Sensor SRS (*): ± 0.08 °C ( TC version only)
Display :
Set Point: -50 to 160°C
Resolution: user-selectable 0.1 , 0.01 C
Units: user-selectable C, F,K
Calibration Volume:
As Liquid Bath: 44.5 x 185 mm
As dry block: 45 x 170 mm ( dry inserts optional)
Heating time: ambient to 120°C: 25 min ( include time to stability)
Cooling time: ambient to -10°C : 25 min (include time to stability)
Thermocouple Input (TC version):
Type: K,J,N,R,S,E,T,B
Range: 0 to 1300 °C
Accuracy: ± 1°C Include CJC error
Resolution: user-selectable 0.1 , 0.01 °C
RTD’S input ( TC version only):
Type: Pt 100 (3/4 wires)
Range: -100 C to 700 °C
Accuracy: ± 0.3 °C
Resolution: user-selectable 0.1 , 0.01 °C
General:
Computer interface: RS 232 as standard ( UBS adapter supplied as option) and EIUK software included
Switch Test: Yes
Ramp: Yes fully programmable
Weight: 10.2 Kg
Dimensions: 160x3350x365 mm
Power Requirement: 115 o 230 V – 50/60 Hz
Power: 300 VA
Notes: * Require SRS sensor and special UKAS matching calibration. Long term drift not included
