EiUK P100-100G Digital Pressure Test Gauge (0 ~ 100 bar)

Range: 0 to 100 bar

Resolution: 0.01

Over Pressure: 150% FS

Accuracy 0.05: 0.05% FS include linearity and hysteresis

Special Function : Min/MAx/TARE/ZERO/FILTER

Temperature range: 0 to 50°C

Temperature coefficient: 0.002 % rdg/°C

Calibrated temperature: 23 C°

Compensated temperature range: 0 to 50°C

Pressure media: all liquid and gas compatible with AISI 316

(non corrosive)

Wetted part: SS Inox 17-4 PH

Pressure unit: mbar, bar, KG/CM2, KPa, psi

Pressure connection: 1/2 “ BSP male for all ranges

Storage temperature: -10 °C to 60°C

Display: graphic, custom LCD display, 16 mm height

Sealing: IP 65

Power supply: 2X AA size alkaline battery (1 year autonomy)

Physical: aluminium case, 86X85X44 (P100 only)

Conformity: 89/336/CEE-93/68/CEE-72/23/CE, EN61010(2001)-EN61326-1-EN 61326/A1
