Full Range: 0.5 tons
Resolution: 0.1 kgs
Load cell weight: 0.3kgs
H1 (max.): 123mm
H2 (max.): 92mm
B (max.): 16mm
L: 84mm
Ø D1 (max.): 31mm
Ø D2 (min.): 21mm
Matching anchor shackle size: 1 /2, 7 /16, 3 /8 inch
Safety factor: 5:1
Accuracy: 0.1% of full range.
Transmission Range: Up to 150m/yds. Up to 3.2 Km / 2 Miles upon request (outdoor, line of sight).
Calibration: User calibration. Initial factory calibration, fullytraceable (certified).
Load Cell Material: high-strength, aerospace quality, alloy steel, polyurethane coated.
Proof Load: Each system proof-loaded to 200% of capacity (certified)
up to a test force of 400t.
Display: 6 digits, ½" (12mm) liquid crystal display. Overload warnings (100%/130%), low battery indication, Gross/Net. Refresh rate 1Hz.
Sampling Rate: 200 per second.
Functions: Zero, Tare, Battery level indication, Low battery warning, Max. (peak hold).
Units: User selectable units (metric tons, short tons, kgs., Ibs., Newtons, Deca-Newtons, Kilo-Newtons)
Indicator/Load Cell Housing: High quality ABS.
Temperature Range:
Load cell: -15°F to +175°F (-25°C to +80°C)
Indicator: -4°F to +158°F (-20°C to +70°C)
Environmental:
Load Cell: IP67
Indicator: IP65
