INPUT
Voltage (AC): 100–120Vac / 200–240Vac ±10%
Fuse: 3.15A / 250Vac
Frequency: 50/60Hz ±5%
AC WITHSTAND VOLTAGE
Output Rating: 3kV / 10mA
Voltage
Range: 0–3.00kV
Resolution: 0.01kV
Accuracy: ± (1.5% of setting 5V)
Current
Hi Limit Range: 0.10–10.00mA
Lo Limit Range: 0.00–10.00mA
Resolution: 0.01mA
Accuracy: ± (2% of setting 2 counts)
Output Frequency
Range: 50Hz / 60Hz
Ramp Up Time
Range: 0.2–60.0s
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
Dwell Time
Range: 0, 0.2–60.0 (0 = continuous)
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
DC WITHSTAND VOLTAGE
Output Rating: 4kV / 5mA
Voltage
Range: 0–4.00kV
Resolution: 0.01kV
Accuracy: ± (1.5% of setting 5V)
Current
Hi Limit Range: 0.02–5.00mA
Lo Limit Range: 0.00–5.00mA
Resolution: 0.01mA
Accuracy: ± (2% of setting 2 counts)
Ramp Up Time
Range: 0.2–60.0s
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
Dwell Time
Range: 0, 0.2–60.0 (0 = continuous)
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
Discharge Time: < 50ms, < 100ms for capacitor load
Maximum Capacitive Load
0.17µF < 1kV
0.09µF < 2kV
0.07µF < 3kV
0.05µF < 4kV
INSULATION RESISTANCE
Output Rating: 4kV / 200GΩ
Voltage
Range: 0.10–4.00kV
Resolution: 0.01kV
Accuracy: ± (1.5% of setting 5V)
Hi/Lo Limit
Range 1
Range: 1–999MΩ
Resolution: 1MΩ
Accuracy: 0.10–0.49kV ± (7% of setting 2 counts)
Accuracy: ≥0.50kV ± (3% of setting 2 counts)
Range 2
Range: 1000–9999MΩ
Resolution: 1MΩ
Accuracy: 0.10–0.49kV ± (20% of setting 2 counts)
Accuracy: ≥0.50kV ± (5% of setting 2 counts)
Range 3
Range: 10.00–99.99GΩ
Resolution: 0.01GΩ
Accuracy: ± (20% of setting 10 counts)
Range 4
Range: 100.0–200.0GΩ
Resolution: 0.1GΩ
Accuracy: ± (30% of setting 10 counts)
Ramp Up Time
Range: 0.1s or 2s
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
Dwell Time
Range: 0, 1.0–999.9s
Resolution: 0.1s
Accuracy: ± (0.1% of setting 0.05 sec)
