EBRO EBI 12-TP190 (1340-6665) Precision Pressure Logger (-20 °C ~ +150 °C)

Manufacturer: EBRO

Model: EBI 12-TP190

Part No.: 1340-6665

Origin: Germany

Warranty: 12 months

Product Description

In the process of H2O2 Sterilizers a very precise pressure measurement is necessary. The system works with pressures down to 1 mbar abs. A Highly accurate pressure data logger is necessary caused by the very low pressure nearly by vacuum.

Measuring range:Pressure: 0,1 mbar ... 1050 mbar Temperature: 0°C ... +85°C

Accuracy:Pressure: 0.25 mbar (0.1 to 50 mbar) ±5 % of measured value (50 to 100mbar) 1 % FS (100 to 1050 mbar) Temperature: ±0.1 °C (0 °C to +85 °C)

Resolution:Pressure: 0,1 mbar ; Temperature: 0,01°C

Operating Temperature:0°C ... +85°C

Memory:50.000 measurement values

Sensor:Pt 1000, piezoresistive pressure sensor

Sample Rate:250 ms...24 h.

Measured variables:Pressure, Temperature

IP Rating:IP68

Battery:Lithium cell, 3.6 V, user replaceable

Dimensions:ø 48 mm x 35 mm

Weight:Aprox. 120 g

Certificate:Factory calibration certificate

Options

- AL 121 dụng cụ mở; Part No. 1100-0131
