Measuring range (mm): 0 -10000
Vertical linearity error: ≤2.5%
Horizontal linearity error: ≤0.1%
Sensitivity margin: ≥62dB
Dynamic scope: ≥34dB
Resolution: ≥36dB
Frequency range (MHz): 0.5-20
Gain（dB）: 0 ～ 110
Velocity: 1000 ～ 15000
Measurement mode: Single, dual, THRU
Reject: 0-80%
Pulse shift (μs): -20 ～ +3400
Zero: (μs) 0.0-99.99
Port type: C9
Operating temperature: -20～50
H×W×D(mm): 240×150×50
Weight (kg): 1.6
