Test Force:
1. Kgf: 0.2kgf / 0.3kgf, 0.5kgf, 1kgf, 3kgf, 5kgf, 10kgf
2. N: 1.96N / 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N
Test Range: 8HV~2500HV
Loading Method: Automatic (Loading/Dwell/Unloading)
Turret: Automatic Shifting turret
Conversion Scale: HHV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Hardness Reading: Touch Screen
Objective: 10X, 20X
Total Magnification: 100× ，200×
Resolution: 0.2μm
Dwell Time: 0~60s
Light Source: LED Cold light source (can be continuous use for 24 hours, no heat generate ensure stable working, servicing life can reach 100,000 hours)
Max. Height of Specimen: 280mm
Throat depth: 320mm
Power Supply: AC220V，50Hz
Execute Standard: ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimension: 550*350*700mm
Net Weight: 60k
