Objective: 20X, 40X
Eyepiece: 10X
Total Magnification: 100X , 200X
Resolution: 0.125um, 0.0625um
Turret Automatic motorized turret
Test Force
1. Kgf: 0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf
2. N: 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N
Test Range: 1HV-2967HV
Loading Method: Automatic (Loading/Dwell/Unloading)
Data Output: Built-in Printer, RS232 Interface
Dwell Time: 0~60s
Light Source: Halogen Lamp
X-Y Test Table: Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm
Max. Height of Specimen: 170mm
Throat: 130mm
Power Supply: AC220V，50Hz
Execute Standard: ISO 6507, ASTM E92, JIS Z2244, GB/T 4340.2
Dimension: 530×280×630mm, Packing Dimension:620×450×740mm
Weight: Net Weight: 35kg, Gross Weight: 47kg
Packing List:
Instrument Main Body 1 set
10X Digital Measuring Eyepiece 1 pc
Diamond Vickers Indenter 1 pc
10X / 20X / 40X Objective (check model number) 2 pcs
Cross Test Table 1 pc
Power Cable 1 pc
Horizontal Regulating Screw 4 pcs
Level 1 pc
Fuse 1A 2 pcs
Halogen Lamp 12V、15~20W 1 pc
Inner Hexagon Spanner 2.5mm 1 pc
Screw Driver 1 pc
Anti-dust Cover 1 pc
Hardness Block 2 pcs
Warranty certificate 1 pc
Usage Instruction Manual 1 copy
