Width: 8.763 mm
Height: 5.867 mm
Length: 10.566 mm
Core Type: Drum
Shielding: Unshielded
Tolerance: 20 %
Inductance: 68 uH
Application: Power
Termination: Standard
Unit Weight: 2.625 g
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 1.7 A
Saturation Current: 1.2 A
Maximum DC Resistance: 189.8 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
