Width: 8.763 mm
Height: 5.867 mm
Length: 10.566 mm
Core Type: Drum
Shielding: Unshielded
Tolerance: 20 %
Inductance: 47 uH
Application: Power
Termination: Standard
Unit Weight: 4.125 g
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 1.4 A
Saturation Current: 1.4 A
Maximum DC Resistance: 146.1 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
