Width: 7.6 mm
Height: 5 mm
Length: 7.9 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 1.5 uH
Application: High Current
Termination: Standard
Unit Weight: 5.244 g
Core Material: Iron Powder
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 13.3 A
Maximum DC Resistance: 6.8 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
