Eaton Souriau-Sunbank SMS3PDH3 Plug Housing 3P QIKMATE PLUG STRAIN RELIEF HOOD

Pitch: 5.08 mm (0.2 in)

Application: Board-to-Board, Cable

Unit Weight: 6 g

Housing Color: Grey

Contact Gender: Pin (Male)

Current Rating: 13 A

Housing Gender: Female

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 1 Row

Voltage Rating: 500 V

Contact Plating: Gold

Housing Material: Polyamide (PA)

Termination Style: Crimp

Number of Positions: 3 Position

Insulation Resistance: 5 GOhms

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 55 C
