Rated input:
Power: 200W
Input voltage: 0-180V
Input current: 0-30A
Range:
CV mode: 0.1~19.999V, 0.1~180.00V
CC mode: 0~3.000A, 0~30.00A
CR mode: 0.05Ω~4.50kΩ
CP mode: 0~200W
Tran Test
Mode: CC，CV
T1&T2: 0.05s~99.999s
Battery Test:
Discharge mode: CC，CR
Maximum discharge capacity: 9999Ah
Resolution: 1mA，10mA，10mΩ，1Ω
Range of measurement:
Voltage read-back value: 0~19.999V,0 ~180.00V
Current read-back value: 0~3.000A,0~30.00A
Power read-back value: 200W
Scope of protection:
Over Voltage Protection(OV): ＞21V OR ＞185V over voltage protection
Over Current Protection(OC): ＞3.1 or ＞31A over current protection
Over Power Protection(OP): 210W
Over Temperature Protection: 85℃
General technical specifications:
Power supply voltage: 100Vac±10%~240Vac±10%，50/60Hz
Display: LCD segment code screen, backlight adjustable
Operating temperature: 0℃ to 40℃
Storage temperature: -10℃ to 70℃
Relative humidity: < 80%
Interface: standard USB, optional RS232(or 485)
Dimensions: 75mm×155mm×240mm (width×height×depth)
Standard accessories:
Three-core power cord * 1
Power fuse * 2
User manual* 1
