Rated input
Power: 400W
Input voltage: 0-150V
Input current: 0-40A
CV mode: 0.1~19.999V，0.1~150.00V
CC mode: 0~3.000A,0~40.00A
CR mode: 0.05Ω~1 kΩ，1 kΩ~4.5kΩ
CP mode: 0~400W
Battery test
Accuracy: CC，CR
Discharge mode: 9999Ah
Maximum discharge capacity: 1mA，10mA，10mΩ，100mΩ
Measuring range:
Voltage readback: 0~19.999V,0 ~150.00V
Current readback: 0~3.000A,0~40.00A
Power readback: 400W
Scope of protection: OVP, OCP, OPP, Over-temperature protection
Power supply voltage: 220Vac±10%, 110Vac±10%, 45-65Hz
Display: 3.5-inch TFT LCD screen with resolution of 480×320
Operating temperature: 0℃ to 40℃
Storage temperature: -10℃ to 70℃
Relative humidity: < 80%
Interface: standard USB, RS232 or 485(optional)
Size: 320mm×220mm×100mm (width × height × depth
Standard accessories:
Three-core power cord 1
Power fuse 2
User manual 1
Optional accessories:
Light disk
USB cable
232 cable
Output wire
