Measurement Parameter: Main parameter: L/C/R/Z; secondary parameter: X/D/Q/θ/ESR
Equivalent mode: Series, parallel
Mode of range: Manual, automatic
Measurement speed: Fast（4 times/s）, medium（2 times /s）, slow（1 times /s）
Configuration of the test terminal: 3-terminal, 5-terminal
Correction function: Short circuit, open circuit
Communication interface: Mini-USB（virtual serial port）
Frequency of test signal: 100Hz, 120Hz, 1kHz, 10kH
Level of test signal: 0.6Vrms
Output impedance: 100Ω
Highest accuracy (see accuracy indicators for details): Resistance: 0.25%; Capacitance: 0.4%
Electrolysis and capacitance mode: No
DCR mode: No
Internal bias: No
Scope of measurement:
L:0-2000H
C：0-20mF
R：0-20MΩ
Correction function: Open circuit correction
Screening function: The limit range can be set to 1%-50%, which is fixed at 1%,5%,10%,20%
Deviation measurement: The percentage of deviation between the nominal value of the component and the setting and display
Other: Adjust backlight brightness, Device USB, automatic shutdown time can be set
ACCESSORIES STANDARD
1,Mini-USB data Wires;
2, power adapter;
3, short circuit chip;
4, red&black rubber plug;
5, large capacity lithium battery
Optional Accessories: Kelvin test clip, SMD test clamp
