DYS DWA – 3000A-MLSS MLSS Analyzer

Function / Features

- Certificate : New Excellent Product (NeP)
- Certificate : Certificate of Patent
- Certificate : Certificate of CE
- English Display
- Real Time Trend Graph Function
- Relay Contact output - HH, L, L, LL & Cleaning Contact
- Simple Operation by 7 Keypad Button
- Large Size LCD Screen (160*128)
- Back-Light LCD
- Isolated(4~20, 0~20, 0~24 mA DC) Output Transmission
- RS-232(Std.), RS485(option) Communication
- Automatic Cleaning Control(Air jet, Water jet) Function
- Wall Mounting
- Microprocessor-based Digital Program Controller

Specifications - Code No. : 413130001MLSS
- Model : DWA-3000A-MLSS
- Channel : Single channel
- Range : 0 ~ 15,000 mg/L (Resolution: 1)
- Measuring Method : IR LED 880nm Transmitted
- Power : AC 110/220V, 50/60Hz, 3VA
- Accuracy : ± 3% of F.S
- Repetition & Reappearance : ± 3% of F.S
- Response time : 30 sec(90% saturation)
- Analog output : 4~20mA DC(STD.)
- Digital output : RS-232C(std.), RS485(option)
- Relay output : HH, H, L, LL & Cleaning Contact
- Display : Trend graph, measuring value
- Humidity : max. 90%(non-condensing)
- IP Rating : IP65
- Size : 240(W)x180(H)x115(D)
- Installation : Wall mounting

Option:
