Weight: 4.8 oz
Accuracy: ± 5 %
Compliance: RoHS 2
Dual Range: N/A
Valve Type: Brass Valve
Scale Length: 2 in
Gas Flow, Max: 0 m³/s
Pressure Type: Gauge
Proof Pressure: Up to 100 psi
Compliance Note: Meets the technical requirements of EU Directive 2011/65/EU (RoHS II)
Liquid Flow, Max: 40 gal/h
Liquid Flow, Min: 8 gal/h
Materials, Wetted: Acrylic, Aluminum, Buna-N (NBR), Nickel Plated Brass
Connection Location: Back Connection
Media Compatibility: Water
Mounting Orientation: Vertical
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 120 °F
Material Construction Option: Nickel Plated Brass
