Dwyer TUF-200-MD Compact Ultrasonic Energy Meter for Heating/Cooling with Flowmeter & Calculator (0.2 GPM, 0.75 in)

Weight: 3.1 lb

Accuracy: ± 2 %, ± 5% with transitional flow

Body Size: DN20

Materials: Plastic

Compliance: CE

Display Type: LCD

Repeatability: 0.01

Data Interface: Modbus

Flow Direction: Unidirectional

Pipe Size, Max: 0.75 in

Supply Voltage: 24 Vac/Vdc

Pressure Limits: Up to 232 psi

Number of Digits: 8

Enclosure Ratings: IP65

Materials, Wetted: 316L Stainless Steel, Brass

Power Consumption: 1 W

Relative Humidity: <93%

Supply Power Note: 24 Vdc/Vac (model dependent)•• or 3.6 V ER26500 lithium metal battery, user supplied and installed, battery acts as back-up if power is lost

Supply Power Type: AC/DC

Pressure Drop, Max: 1.5 psi

Media Compatibility: Alcohols, Compatible Liquids, Oils, Water

Mounting Orientation: Horizontal, Vertical

Electrical Connection: Screw Terminal

Nominal Flow Rate, Max: 11 gal/min

Process Connection Size: 1 in

Process Connection Type: BSPP Male

Process Temperature, Max: 203 °F

Process Temperature, Min: 36 °F

Volumetric Flow Rate, Max: 22 GPM

Volumetric Flow Rate, Min: 0.2 GPM

Operating Temperature, Max: 131 °F

Operating Temperature, Min: 41 °F
