Weight: 1.98 lb
Cv Factor: 4.5 gal/min
Materials: Nylon
Compliance: CE
Orifice Size: 0.51 in
Supply Voltage: 110 Vac
supply-voltage: 110 Vac
Pressure Limits: Up to 246.6 psi
Enclosure Ratings: IP54, NEMA Type 13
Materials, Wetted: Brass, Buna-N (NBR), Stainless Steel
Power Consumption: Inrush: 55 VA, Holding: 22 VA
Supply Power Type: AC
Type of Operation: Normally Closed
Media Compatibility: Consult Factory
Mounting Orientation: None
Electrical Connection: DIN 43650 A (solenoid valve)
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Operating Pressure Range: 7.3 to 188.5 psi
Operating Temperature, Max: 149 °F
Operating Temperature, Min: 32 °F
