Weight: 3 lb
Linearity: ± 1.0%
Materials: Brass
Compliance: CE
Wire Gauge: 22 AWG
Sensor Type: Insertion
Output Detail: Analog 4 to 20 mA Transmitter, 4 mA is 0 ft/s to 1.2 ft/s, 20 mA is 25 ft/s
Repeatability: ± 0.5%
Supply Voltage: 10 to 35 Vdc
Pressure Limits: Up to 400 psi
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67
Materials, Wetted: 316 Stainless Steel, Brass, FKM, PTFE, Tungsten Carbide
Power Consumption: 40 mA
Supply Power Type: DC
Media Compatibility: Water-based fluids
Pressure Limits Note: (27.6 bar) @ 100°F (37.8°C), 325 psig (22.4 bar) @ 212°F (100°C).
Electrical Connection: Cable
Linear Flow Rate, Max: 25 ft/s
Linear Flow Rate, Min: 1.2 ft/s
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Male
Operating Temperature, Max: 212 °F
Operating Temperature, Min: -40 °F
