Filter: 100 μ or better
Weight: 0.14 kg
Accuracy: ± 20 %
Wire Gauge: 22 AWG
Port 1 Size: 1/4 in
Port 1 Type: Quick Coupling Male
Port 2 Size: 1/4 in
Port 2 Type: Quick Coupling Male
Sensor Type: Compatible Liquids
Switch Type: SPST NO
Accuracy Note: 20% of set point
Pressure Type: Gauge
Repeatability: ± 1%
Switch Rating: 0.08 A @ 120 Vac
Pressure Limits: Up to 125 psi
Sensor Material: Polypropylene, PPS composite, Stainless Steel, Fluorocarbon
Mounting Orientation: Vertical Lead wires Down
Pressure Limits Note: 125 psig (8.6 bar) @ 70°F (21°C), 50 psig (3.4 bar) @ 212°F (100°C)
Electrical Connection: Pigtail Leads
Actuation Set Point, Max: 1 GPM
Operating Temperature, Max: 212 °F
Operating Temperature, Min: 0 °F
