Weight: 4.9 oz
Accuracy: ± 2 µA
Compliance: ATEX, CL, FM, UL
Inductance: FM: 3.05 mH, BASEEFA: 3.05 mH
Capacitance: FM: 0.083 µF, BASEEFA: 0.083 µF
Output Detail: 4 to 20 mA
Output Signal: Current
Certifications: BASEEFA: IIC, FM: A & B
LED Indicators: Green: Power indication
Supply Voltage: 20 to 35 Vdc
Terminal block: up to 2.5 mm²
Load Resistance: 0 to 500 Ω
Electrical Safety: 28 µV 300 Ω 93 mA
Relative Humidity: 5 to 95% RH
Supply Power Note: 20-35 Vdc w.r.t. earth
Supply Power Type: DC
Input Voltage Note: 16.2 V at 20 mA with 250 Ω load (negative w.r.t. earth); 11.0 V at 20 mA with 500 Ω load (negative w.r.t. earth)
Input Control Signal: 16.2 Vdc
Storage Temperature, Max: 176 °F
Storage Temperature, Min: -40 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: -4 °F
