Weight: 0.71 oz
Contacts: Silver with Brass Terminals
Compliance: cUL, UL
Switch Note: SPDT normally open or normally closed, 15 A @ 125/150 Vac
Switch Type: SPDT NO/NC, Selectable
Pressure Type: Gauge
Pressure, Max: 111 inH₂O
Pressure, Min: 28 inH₂O
Repeatability: ± 20%
Switch Rating: 15 A @ 125/150 Vac
Pressure Limits: Up to 111 inH2O
Materials, Wetted: Polyurethane
Media Compatibility: Air, Alkaline solutions, Argon, Carbon dioxide, Dilute Acids, Helium, Nitrogen, Oxygen, Steam, Water, Water-based fluids
Mounting Orientation: Panel Mount
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Operating Temperature, Max: 150 °F
Operating Temperature, Min: 40 °F
