Weight: 2.52 lb
Accuracy: ± 0.25 %
Mounting: Suspended Below Point Being Monitored
Compliance: CE
Protection: Surge/Lightning Protected Per EN61000-4-5, Class 5
Cable Length: 60 ft
Output Detail: 4 to 20 mA DC, 2-wire
Output Signal: Current
Pressure, Max: 10 psi
Response Time: <50 ms
Proof Pressure: 2x Full Scale
Supply Voltage: 10 to 33 Vdc
Thermal Effect: ± 0.0075%/°F
Loop Resistance: 1000 Ω @ 30 Vdc max
Electrical Output: 4 to 20 mA
Materials, Wetted: FKM, Polyamide, Polyether, Polyethylene, Polyurethane, PTFE, Stainless Steel
Supply Power Type: DC
Media Compatibility: Consult Factory
Electrical Connection: Pigtail Leads
Operating Temperature, Max: 176 °F
Operating Temperature, Min: -4 °F
Compensated Temperature, Max: 140 °F
Compensated Temperature, Min: 32 °F
Material Construction Option: Polyether Polyurethane cable jacket
