Weight: 0.75 lb
Deadband: 20 to 35 psi
Compliance: CE
Switch Type: DPST Snap NO
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 30 psi
Repeatability: ± 5 psi
Switch Rating: 20 A @ 120 Vac, 12 A @ 240 Vac, 9.6 A @ 240 Vac (3 phase), 8.6 A @ 32 Vdc, 3.1 A @ 120 Vdc, 1.6 A @ 240 Vdc.ac
Pressure Limits: Up to 179 psi
Enclosure Ratings: None
Materials, Wetted: Silicone, Stainless Steel, Steel
Media Compatibility: Consult Factory
Mounting Orientation: Not Position Sensitive
Set Point Adjustment: Internal Screw
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Operating Temperature, Max: 140 °F
