Weight: 113 g
Accuracy: ± 0.8 %
Materials: Stainless Steel, PC-ABS
Display Type: N/A
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 2.5 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 15 psi
Supply Voltage: 12 to 32 Vdc
Number of Wires: 3
Thermal Effects: ± 0.054% FS/°C
Electrical Output: 0 to 10 V
Supply Power Type: DC
Connection Location: Bottom
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Electrical Connection: Screw Terminal
Process Connection Size: 3/16 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 77 °C
Operating Temperature, Min: -18 °C
Compensated Temperature, Max: 77 °C
Compensated Temperature, Min: 4.4 °C
Zero Setting Adjustable Range: Accessible under the small terminal cover
