Accuracy: ± 0.1 %
Impedance: 700 Ω @ 24 dc
Compliance: CE
Input Note: 2 or 3-wire Pt100 RTD (models 651A)
Sensor Type: Thermocouple
Output Detail: Linearized 4 to 20 mA, 2-wire loop powered
Output Signal: Current
Response Time: 2 ms
Current Output: 4 to 20 mA
Supply Voltage: 10 to 32 Vdc
Number of Wires: 2
Measurement Type: Thermocouple
Supply Power Note: 10 to 32 VDC, reverse connection protected.
Supply Power Type: DC
Response Time Note: 70% in 2 ms
Span Temperature Drift: 0.0036%/°F
Zero Temperature Drift: 0.09%/°F
Temperature Input Range: 32 to 1112 °F
Storage Temperature, Max: 160 °F
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
