Weight: 283 g
Accuracy: ± 1 %
Compliance: CE
Accuracy Note: 626: 0.25% FS; 626: 0.20% RSS; 628: 1.0% FS; 628: 0.5% RSS; 626 Absolute Ranges: 0.5% FS; 626 absolute ranges: 0.30% RSS. (Includes linearity, hysteresis, and repeatability.)
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 0 psi
Response Time: 300 ms
Burst Pressure: 500 psi Maximum
Proof Pressure: Up to 200 psi
Supply Voltage: 10 to 35 Vdc
Compliance Note: CE, Optional: NSF/ANSI 61/372, ANSI/UL 218, ANSI/UL 508, NEPA 20
Loop Resistance: 0 to 1000 Ω max
Thermal Effects: ± 0.02% FS/°F (includes zero and span)
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: 316L Stainless Steel
Power Consumption: 38 mA
Supply Power Note: 10 to 30 VDC (for 4 to 20 mA, 0 to 5, 1 to 5, 1 to 6 VDC outputs); 13 to 30 VDC (for 0 to 10, 2 to 10 VDC outputs); 5 VDC ± 0.5 VDC (for 0.5 to 4.5 VDC ratio to metric output), 10 to 35 VDC (for 4 to 20 mA with to CB option); 13 to 35 VDC or isolated 16 to 33 VAC (for selectable output with to CB option)
Supply Power Type: DC
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Housing Construction: Conduit Box Housing
Mounting Orientation: Not Position Sensitive
Electrical Connection: Cable Gland with Cable
electrical-connection: Cable Gland with Cable
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 200 °F
Operating Temperature, Min: 0 °F
Compensated Temperature, Max: 175 °F
Compensated Temperature, Min: 0 °F
