Weight: 51 g
Accuracy: ± 0.25 %
Compliance: CE
Display Type: N/A
Mounting Note: Vertical with Downward Pressure Ports
Output Detail: Field Selectable
Output Signal: Current, Voltage
Pressure Type: Differential
Pressure, Max: 0.4 inH₂O
Pressure, Min: 0 inH₂O
Response Time: 2.5 Hz
Burst Pressure: 10 psi Maximum
Proof Pressure: Up to 1 psi
Supply Voltage: 2-Wire: 10 to 35 Vdc, 3-Wire: 17 to 36 Vdc/21.6 to 33 Vac
Compliance Note: CE, optional plenum rated units meet UL Standard 2043
Loop Resistance: Current Output: 0 to 1250 Ω max, Voltage Output: Load resistance 1 kΩ min.
Number of Wires: 2, 3
Span Adjustment: Push Button
Electrical Output: 4 to 20 mA, 0 to 10 Vdc
Enclosure Ratings: IP20, NEMA Type 1
Materials, Wetted: Consult Factory
Power Consumption: max 40 mA
Supply Power Type: AC/DC
Response Time Note: 2.5 Hz sample rate
Long Term Stability: ± 1% FSO/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Electrical Connection: Screw Terminal
Process Connection Note: Barbed, dual size ID rubber or vinyl tubing
Process Connection Size: 1/8 in, 3/16 in
Process Connection Type: Stepped Barb Fitting
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -17.8 °C
Zero Setting Adjustable Range: Push button
