Dwyer 607D-14 DIN Rail Differential Pressure Transmitter, 4-20 mA, 0.1-25 inH2O (Differential, 0.5 inH₂O, Barbed Fitting, 1/8 in)

Weight: 198 g

Accuracy: ± 0.25 %

Compliance: CE

Display Type: N/A

Accuracy Note: ± 0.25% FS* at room temperature. *RSS includes non-linearity, hysteresis and non-repeatability

Mounting Note: Vertical

Output Signal: Current

Pressure Type: Differential

Pressure, Max: 0.5 inH₂O

Pressure, Min: -0.5 inH₂O

Response Time: 10 ms

Proof Pressure: Up to 15 psi

Supply Voltage: 16 to 32 Vdc

Loop Resistance: 0 to 800 Ω max

Thermal Effects: ± 0.01 FS/°F

Electrical Output: 4 to 20 mA

Materials, Wetted: 302 Stainless Steel, Brass, Glass, Nickel, Silicone

Supply Power Type: DC

Long Term Stability: ± 1% FS/year

Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

Mounting Orientation: 1.378" DIN rail

Thermal Effects Note: (Includes zero and span) ± 0.01 FS/°F, 20 to 170°F (-7 to 77°C).

Electrical Connection: Screw Terminal

Process Connection Note: Barbed fittings ID rubber or vinyl tubing

Process Connection Size: 1/8 in

Process Connection Type: Barbed Fitting

Storage Temperature, Max: 85 °C

Storage Temperature, Min: -54 °C

Operating Temperature, Max: 77 °C

Operating Temperature, Min: -18 °C

Compensated Temperature, Max: 77 °C

Compensated Temperature, Min: -18 °C

Zero Setting Adjustable Range: Potentiometer
