Dwyer 476A-0 Digital Pressure Differential Manometer, -20 to 20 inH2O, ± 1.5% FS, Aluminum (± 1.5 %, 20 inH₂O, Tubing, 1/4 in)

Kit: None included

Weight: 10.8 oz

Accuracy: ± 1.5 %

Compliance: CE

Hysteresis: ± 0.1%

Display Note: 4 digit LCD (.425˝H x .234˝W digits)

Display Type: LCD

Accuracy Note: ± 1.5% FS at 72°F (22.2°C). Includes linearity and repeatability

Pressure, Max: 20 inH₂O

Pressure, Min: -20 inH₂O

Pressure Limits: Up to 5 psi

Thermal Effects: 0.05% FS/°F

Major Resolution: 0.02 inH2O

Measurement Type: Pressure

Number of Digits: 4

Materials, Wetted: Consult Factory

Supply Power Type: Battery

Media Compatibility: Air, Argon, Compatible Gases, Nitrogen

Battery Size and Type: Alkaline 9V

Operating Pressure, Max: 5 psi

Process Connection Size: 1/4 in

Process Connection Type: Tubing

Operating Temperature, Max: 140 °F

Operating Temperature, Min: 0 °F

Compensated Temperature, Max: 104 °F

Compensated Temperature, Min: 32 °F
