Pressure Type: Differential
Pressure Port Size: 1/4" NPT Female
Pressure Range: 0 to 2 psi
Accuracy Value: ±3%
Accuracy Class: > 0.25%
Dial Size: 5"
Service: Aluminum case: Air and compatible gases and oil based liquids; Brass case: Air and compatible gases and water based liquids.
Wetted Materials: Consult factory.
Housing: Die cast aluminum with impregnated hard coating, standard. Optional forged brass housing is required for water or water based fluids. Special material diaphragms available, contact factory.
Accuracy: ±3% of FS at 70°F (21.1°C). (±4% on 4200. 4210. 4215, 4220. 4300. 4400. and 4500).
Pressure Limits: -20˝ Hg to 500 psig (-0.677 bar to 34.4 bar).
Temperature Limits: 20 to 200°F (-6.67 to 93.3°C).
Size: 4˝ (101.6 mm) diameter dial face.
Mounting Orientation: Diaphragm in vertical position. Consult factory for other position orientations.
Process Connections: 1/4˝ female NPT high and low pressure taps, duplicated -one pair top for air and gas, and one pair bottom for liquids.
Weight: 3 lb, 3 oz (1.45 kg) aluminum case; 7 lb, 13 oz (3.54 kg) brass case.
See more detail information in the Datasheet
