Weight: 4 oz
Accuracy: ± 0.25% span ± 1 least significant digit
Compliance: CE, UL
Input Type: Thermocouple, RTD, DC Voltage or DC Current
Output Note: Proportional current: 0 to 20 mADC scaleable into 600 Ohms max
Display Note: Two 4-digit, 7 segment, 0.259 high (6.35 mm) LEDs
Display Type: LED
Memory Backup: Non-Volatile
Control Output: Proportional Current
Supply Voltage: 100 to 240 Vac/132 to 240 Vdc
Output Type (A): Current
Output Type (B): N/A
RTD Input Range: JPt 100: -4 to 752°F; Pt 100: -328 to 1562°F; Ni 120: -112 to 572 °F; Cu 50: -58 to 302 °F
Number of Digits: 4
Enclosure Ratings: IP66, NEMA Type 4X
Power Consumption: max 5 VA
Supply Power Note: 100 to 240 VAC, nominal, +10 - 15%, 50 to 400 Hz. single phase; 132 to 240 VDC, nominal, +10 - 20%
Supply Power Type: AC/DC
Voltage Input Range: 0 to 5 V, 0 to 10 V
Current Output Range: 0 to 20 mA dc
Input Control Signal: 0 to 20 mA
Mounting Orientation: 1/32 DIN
Temperature Sensor Type: RTD or Thermocouple
Operating Temperature, Max: 131 °F
Operating Temperature, Min: 14 °F
Thermocouple Input Range Note: Type K: -328 to 2372°F; Type J: -148 to 2192°F; Type T: -328 to 752°F; Type E: 32 to 1112°F; Type W: -328 to 2372°F; Type R: 32 to 3092°F; Type S: 32 to 3092°F; Type B: 212 to 3272°F; Type L: -328 to 1562°F; Type U: -328 to 932°F
