Winding Resistance Measurement:
Test current: 5 mA – 40 A
Open voltage: Up to 55 V
OLCT DVtest (DRM): 0.1 ms
Output power: 900 W
Measurement range: 0.1 μΩ - 100 kΩ
Typical accuracy:
0.1 μΩ – 1.999 kΩ:± (0.1% rdg + 0.1% F.S.)
2 kΩ – 9.999 kΩ: ± (0.2% rdg + 0.1% F.S.)
10 kΩ – 100 kΩ: ± (1.0% rdg + 1.0% F.S.)
Measurement range / Resolution:
0.1 μΩ – 999.9 μΩ/ 0.1 μΩ
1.000 mΩ – 9.999 mΩ/ 1 μΩ
10.00 mΩ – 99.99 mΩ/ 10 μΩ
100.0 mΩ – 999.9 mΩ/ 0.1 mΩ
1.000 Ω – 9.999 Ω/ 1 mΩ
10.00 Ω – 99.99 Ω/ 10 mΩ
100.0 Ω – 999.9 Ω/ 0.1 Ω
1.000 kΩ – 9.999 kΩ/ 1 Ω
10.00 kΩ – 99.99 kΩ/ 10 Ω
Temperature Measurement
Measurement range: -50 ºC – +180 ºC / -58 ºF – +356 ºF
Thermometer Pt100 class B
Resolution 0.1 ºC
Operating temperature: -20 °C – +60 °C / -4 °F – +140 °F
Storage & transportation temperature: -40 °C – +70 °C / -40 °F – +158 °F
Humidity: 0 – 95% relative humidity, noncondensing
Weight: 13.5 kg/ 29.7 lbs
Dimension (WxHxD): 478 x 194 x 389 mm (18.82 x 7.64 x 15.33 in)
