Battery
Type: Li-Po (User-replaceable)/ 2-cell, 4400 mAh
Recharge time: 2 hours
AC Adapter
Input voltage: 90 – 264 V AC, 50/60 Hz
Output voltage: 12 V DC
Output current: 3 A
Output data
Test current range: 1 – 100 A DC
Maximum DC output voltage @Imax: 8.4 V
Measurement
Resistance range: 0.1 μΩ – 3000 mΩ
Resolution:
0.1 – 999.9 μΩ; 0.1 μΩ
1.000 – 9.999 mΩ; 0.001 mΩ
10.00 – 99.99 mΩ; 0.01 mΩ
100.0 – 999.9 mΩ; 0.1 mΩ
1000 – 3000 mΩ; 1 mΩ
Typical accuracy*
± (0.1 % rdg + 0.1 % FS) - up to 1 Ω range
± (0.25 % rdg + 0.25 % FS) - from 1 Ω to 3 Ω
Memory
Internal: 2 GB SD Card
RMO-H can store up to 1000 measurements*
Environment conditions
Operating temperature: -10 ºC - +55 ºC / +14 ºF - +131 ºF
Storage & transportation temperature: -40 ºC - +70 ºC / -40 ºF - +158 ºF
Humidity 5 % - 95 % relative humidity, non-condensing
Dimensions (L x W x D): 226 mm x 116 mm x 50 mm/ 8.9 in x 4.5 in x 1.9 in
Weight: 0.95 kg / 2.1 lbs
Included accessories:
USB with DV-Win PC software
Ground (PE) cable
Carrying belts
Plastic transport case – medium size
Standard accessories: 2 x 5 m combined current & sense leads with TTA clamps
