Max output current (220V supply): 9.0kA
Max output current (380V supply): 14kA
Output current measuring range (Mode "A"): 10-1000A
Output current measuring range (Mode "kA"): 14A-14kA
Test current duration measuring range: 500ms-990ms; 1s-7200s
Current measuring accuracy: 1.5% of range
Duration measuring accuracy: 3% of reading
Max testing duration at max output current: 10s
Power consumption: max 55kvA
Supply voltage: 220V+/-22V or 380V+/-38V
Frequency: 50+/-1 Hz
Control unit net weight: 27kg
Current source net weight: 27kg
Control unit dimensions: 450x250x475 mm
