Dimensions (H x W x D): 130 x 48 x 44 mm (5.12 x 1.89 x 1.73 in)
Weight: typically 220 to 250 g (7.76 to 8.82 oz), depending on sensor equipment
Housing: robust 2-component housing
Display: Matrix display with high resolution
Ambient conditions
Temperature: -20 to +50°C (-4 to 122 F) (Measurement and storage) | -40 to +50°C (-40 to 122 F) (Use in potentially explosive atmospheres)
Pressure: 700 to 1,300 mbar (Measurement)
800 to 1,100 mbar (Use in potentially explosive atmospheres)
Relative humidity: 10 to 95 % r.h. | 5 to 95 % r.h. short term
Protection class: IP 68
Alarms
Visual: 3 LED 'red' (gas alarms) | 3 LED 'yellow' (device alarms)
Acoustic: Multi-tone > 90 dB at 30 cm (12 in)
Vibration
More technical specifications
Energy supply: NiMH battery, rechargeable, replaceable by user
Bluetooth®:
Bluetooth 5.0 (disabled for some countries outside the EU and outside North America, but can be retrofitted. Contact DrägerService.)
Operating times:
For CatEx SR and PID sensor: typical 12 h (Bluetooth® active),
For IR sensor: typical 50 h (Bluetooth® active)
Operating with electrochemical sensors only: typical 100 h
Charging time: < 4 h
Ready for Measurement < 60 s after switch-on (CatEx SR and electrochemical sensors)
Data logger: Application of an optimised data compression method with high
accuracy and large storage capacity. (Typically data compression >90 % compared to the traditional data logger concept with adjustable interval)
Approvals
Marking Explosion protection:
ATEX: I M1 Ex da ia I Ma | II 1G Ex da ia IIC T4 Ga (usable in Ex-Zone 0)
IECEx: Ex da ia I Ma | Ex da ia IIC T4 Ga (usable in Ex-Zone 0)
cCSAus (USA and Canada): CSA approval cCSAus
Class I, Zone 0, AEx da ia IIC T4/T3 Ga
Class I, Division I, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
EAC: Contact Dräger for availability
Directives: 2014/34/EU (ATEX), 2014/53/EU (RED), 2011/65/EU (RoHS)
Consisting of: Basic device (with data logger), delivery with manufacturer and calibration certificate.
Datasheet
Matching sensor
Product | Order number |
DrägerSensor CatEx SR | 6851900 |
DrägerSensor PID HC neo | 6800417 |
DrägerSensor XXS Amine | 6812545 |
DrägerSensor XXS CI2 | 6810890 |
DrägerSensor XXS CO / H2 compensated | 6811950 |
DrägerSensor XXS CO HC | 6812010 |
DrägerSensor XXS CO LC | 6813210 |
DrägerSensor XXS CO LC / H2S LC | 6813280 |
DrägerSensor XXS CO2 | 6810889 |
DrägerSensor XXS COCI2 | 6812005 |
DrägerSensor XXS H2 | 6812370 |
DrägerSensor XXS H2 HC | 6812025 |
DrägerSensor XXS H2S HC | 6812015 |
DrägerSensor XXS H2S LC | 6811525 |
DrägerSensor XXS HCN | 6810887 |
DrägerSensor XXS HCN PC | 6813165 |
DrägerSensor XXS NH3 | 6810888 |
DrägerSensor XXS NO | 6811545 |
DrägerSensor XXS NO2 | 6810884 |
DrägerSensor XXS NO2 LC | 6812600 |
DrägerSensor XXS O2 | 6810881 |
DrägerSensor XXS O2 / CO LC | 6813275 |
DrägerSensor XXS O2 / H2S LC | 6814137 |
DrägerSensor XXS O2 100 | 6812385 |
DrägerSensor XXS O2 PR | 6800530 |
DrägerSensor XXS Odorant | 6812535 |
DrägerSensor XXS OV | 6811530 |
DrägerSensor XXS OV-A | 6811535 |
DrägerSensor XXS Ozone | 6811540 |
DrägerSensor XXS PH3 | 6810886 |
DrägerSensor XXS PH3 HC | 6812020 |
DrägerSensor XXS SO2 | 6810885 |
