Technical Specifications
Input voltage: DC 24V ±10%
Input current: Max. 300mA
Power consumption: Max. 8W
Emitter voltage: ±4.75kV~ ±5.5kV (4 level adjustable)
Output frequency: 0.5Hz ~ 100Hz (Adjustable)
Ion generating method: Corona discharge
Voltage application method: Pulsed AC
Material: Body: ABS / Emitter pins: Tungsten
Emitter replacement: Replaceable
Ion balance: Under average ±35V (@distance 50mm)
Coverage distance: 10mm ~ 300mm
Compressed Air Specifications
Type: CDA (Clean Dry Air), N2
Pressure: 0.05 ~ 0.3 MPa (Usually under 0.2MPa)
Flow (Per 1 emitter): 2L/min (±10%) (Under 0.1MPa)
Air tube diameter: Ø6 (Outside)
Environmental Conditions
Ozone generation: Under 0.005ppm
Ambient temperature: 0°C ~ +50°C (32°F ~ 122°F)
Ambient humidity: 35% ~ 85%RH (No condensation)
Length: 628 mm
