Diodes Incorporated PAM8013AKR 1-Channel Mono 3W Mono Class D Audio Amp 5mA

Gain: 18 dB

Class: Class-D

Shutdown: Shutdown

Unit Weight: 39.545 mg

Output Power: 3 W

Mounting Style: SMD/SMT

THD plus Noise: 0.17 %

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.8 V

Audio - Load Impedance: 4 Ohms

Operating Supply Current: 5 mA

Operating Supply Voltage: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 25 C

PSRR - Power Supply Rejection Ratio: - 68 dB
