Width: 3.5 mm
Height: 1.6 mm
Length: 6.5 mm
Unit Weight: 112 mg
REACH - SVHC: Details
Configuration: Single Dual Collector
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 2 W
DC Current Gain hFE Max: 10000
Emitter- Base Voltage VEBO: 10 V
Collector- Base Voltage VCBO: 30 V
Continuous Collector Current: 1 A
Maximum DC Collector Current: 1 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 10000 at 10 mA at 5 V, 20000 at 100 mA at 5 V, 5000 at 1 A at 5 V
Maximum Collector Cut-off Current: 100 nA
Collector- Emitter Voltage VCEO Max: 30 V
