-Enclosure: Designed to NEMA4X/IP55. Suitable for continuous outdoor use.
-Accuracy:0.1% of capacity up to EDx-50T.* 0.3% of capacity for EDx-75T and above.*
-Repeatability:0.1% of capacity up to EDx-50T.* 0.3% of capacity for EDx-75T and above.*
* Normal resolution mode with Dillon provided shackles.
-Proof Load:150% of capacity up to EDx-75T. 110% of capcity Edx-100T and above.
-Ultimate Overload:See table on reverse.
-Safe Overload:200% of capacity
-Body Protection: Aluminum and alloy steel capacities are powder coated.
-Bearings: Unmatched repeatability attained by needle bearings in
shackle pin holes up to EDx-5T. Shackle pin acts as inner race.
-Shackles: Forged industry standard anchor shackles. Models up to EDx-5T
use precision machined shackle pin. Higher capacities use bar stock pin.
-Display: 128 x 64 dot-graphic LCD display shows up to 6 digits 1.0” (26 mm)
high plus annunciators and softkeys. Digits are .11 inches (3 mm) thick
for unmatched readability.Display Update Rate:2 times per second.
-Peak Capture Rate:10/100/1,000 Hz
-Connector:Recessed sealed connector may be used for serial
communications or connection to a Communicator II remote.
-RS-232 Communication: Print or extract data easily. Continuous output
can drive a scoreboard. Configurable poll character.
-Calibration: Traceable to the National Institute of Standards and
Technology. Certificate included with curve of readings. Passes only
with three consecutive confirming runs, with all points in specification.
-Battery Life: Stand alone EDXtreme with no radio and no backlight lasts
up to 400+ hours. 150 hours continuous with Radio Link System. Use
with two C-Cell alkaline batteries. (When using backlight, battery life
will be reduced, depending on intensity.)
-Operating Temperature:-4° F to 158° F (-20° to 70° C)
-Included with Instrument:All include certificate of calibration, manual
and batteries. Plastic carry case included for EDx-1T to EDx-50T.
-Higher capacities include rugged plywood storage crate. Instruments with shackles include centering spacers (EDx-20T & up) and
shackle storage crate (EDx-20T to EDx-75T). Display backlight.
-Options:Shackles. Radio communications.
-Included with Remote:Carry case and batteries
-Accessories:Rubberized case protector sleeve.
Remote wall mount bracket. Serial and remote cable assemblies.
