DILLON EDjr-10T Dynamometer (100,000 N)

Capacity x Resolution:

25,000 lbf x 20

10,000 kgf x 10

100,000 N x 100

Enclosure: Designed to NEMA4X/IP55.

Suitable for continuous outdoor use.

Accuracy: 0.2% of capacity

Repeatability: 0.2% of capacity

Proof Load: 150% of capacity

Safe Overload: 200%

Display: 128 x 64 dot-graphic LCD display shows all digits 1.0” (26 mm) high plus annunciators and softkeys

Display Update Rate: 2 times per second

Peak Hold Sampling Rate: 10 times per second typical

RS-232 Communication: Not available. See Dillon EDXtreme.

Calibration: Traceable to the National Institute of Standards and Technology. Calibration card included.

Battery Life: 425 hours typical use with two C-cell alkaline batteries

Backlight: Configurable. Using backlight will consume more battery power, reducing battery life.

Operating Temperature: -4°F to 158°F (-20° to 70°C)

Included with Instrument: Carry case, batteries, manual and calibration card
