Structure: All-in-one structure, the door uses explosion-proof lock and explosion-proof chain
Drop Ball Weight: 9.1kg±0.1kg
Dropping Height: 0~770mm（Adjustable)
Control Mode: PLC Touch Screen Control+ Remote Control
Crossing Bar Diameter: 15.8 mm
Inner Cabinet Dimension: W500 X D300 X H800mm
Effective Test Space: W300XD300XH300mm
Internal Material: 1.0mm thickness SUS 304# Stainless steel (reinforced). Total 80mm thickness together with external chamber.
External Material: 1.5mm thickness Cool-rolled plate
Air Vent: Diameter: 150mm, at the top of chamber back
Observation Window: 390 X 360mm (20mm thick explosion-proof glass, install explosion-proof stainless steel mesh)
Lifting Mode: Electric
Top / Bottom Impact Surface: Steel Plate
Test Space: W300XD400XH200 mm
Overall Dimensions: W940XD780XH1620 mm
Power Supply: AC 220V / 2.0KW
Data Output: Test data can be output by USB flash disk directly .
Safety Protection: Explosion-proof pressure relief device, smoke exhaust device, fire extinguishing system, electronic door lock system, safety stop switch
Options: Temperature acquisition system, voltage acquisition system, video monitoring system
