Wavelengths (nm): 850/1300/1310/1550
Dynamic range (dB): 25/27/37/35
Wavelength Accuracy: ± 20nm
Event Dead Zone:
Single-mode: ≤0.8m
Multi-mode: ≤0.8m
Attenuation Dead Zone:
Single-mode: ≤4m
Multi-mode: ≤5m
Distance Range:
Single-mode: 100m, 400m, 1.5km, 3km, 6km, 12km, 25km, 50km, 100km, 200km, 400km
Multi-mode: 100m, 400m, 1.5km, 3km, 6km, 12km, 25km, 50km
Pulse Width:
Single-mode: 3ns, 5ns, 10 ns, 30 ns, 50 ns, 100 ns, 200 ns, 500 ns, 1μs, 2μs, 5μs, 10μs, 20μs
Multi-mode: 5ns, 10ns, 30ns, 50ns, 100ns, 200ns, 500 ns, 1μs
Sampling Resolution: 5cm ~ 6.4m
Sampling Points: 256,000 max
Distance Accuracy (m): ±(0.75m + 0.005% x Distance + Sampling Resolution)
Group Refractive Index: 1.300000 ~ 1.700000
Loss Threshold: 0.01dB
Loss Resolution: 0.001 dB
Refresh Rate: 4 fields/second
Reflectance Accuracy: ± 2dB
Measurement Time Range: 5s ~ 5min, real time
Data Storage: >10,000 OTDR traces, exportable to USB or PC
