Color: Gray
Pitch: 10.01 mm (0.394 in)
Width: 18.37 mm
Gender: Plug (Male)
Height: 23.73 mm
Length: 28.4 mm
Material: Plastic
Dimensions: 18.37 mm x 23.73 mm x 28.4 mm
Insulation: Insulated
Unit Weight: 9.200 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Socket (Female)
Current Rating: 13 A
Housing Gender: Plug (Male)
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: DT04-3P
Number of Positions: 3 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
