DEUTSCH - TE Connectivity DRC26-24SB Housings 24P PLUG ASM

Color: Black

Pitch: 4.42 mm (0.174 in)

Width: 50.9 mm

Gender: Plug (Male)

Height: 36.45 mm

Length: 27.94 mm

Material: Plastic

Dimensions: 50.9 mm x 36.45 mm x 27.94 mm

Insulation: Insulated

Row Spacing: 4.42 mm

Unit Weight: 65 g

Mating Gender: Receptacle

Contact Gender: Socket (Female)

Current Rating: 7.5 A

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 4 Row

Voltage Rating: 250 V

Wire Gauge Max: 16 AWG

Wire Gauge Min: 22 AWG

Wire Gauge Range: 22 AWG to 16 AWG

Termination Style: Crimp

Mating Part Number: DRC23-24P

Number of Positions: 24 Position

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
