Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to 109 / 123 / 152 / 189 psig )
Capacity(FAD)*:
50Hz (Min-Max): 1.18-1.97 / 1.06-1.76 / 0.87-1.45 / 0.68-1.13 m³/min ( equivalent to 42-70 / 37-62 / 31-51 / 24-40 cfm )
60Hz (Min-Max) : 1-1.66 / 0.98-1.64 / 0.87-1.45 / 0.67-1.12 m³/min ( equivalent to 35-59 / 34-58 / 31-51 / 24-40 m³/min )
Installed motor power: 11kW; 15 hp
driving mode & Cooling method: Belt Driven
Noise level ** (dBA): 62
Dimensions(mm) LxWxH: 1050x650x900
Weight (kg): 410
Air outlet pipe diamete: R3/4"
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
